行程：粗調360º/微調10º
讀取精度：5' (SR160A為1º)
型錄下載
| 型號 | 檯面尺寸 (mm) |
厚度 (mm) |
分厘卡頭 每格讀值 |
荷重 (kgf) |
| SR40A | Ø38 | 20 | ~1.44' | 1 |
| SR60A | Ø60 | 25 | ~0.92' | 3 |
| SR60A-L | Ø60 | 15 | ~0.96' | 3 |
| SR80A | Ø80 | 25 | ~0.67' | 4 |
| SR85A | Ø85 | 25 | ~0.72' | 4 |
| SR90A | Ø90 | 25 | ~0.61' | 4 |
| SR90A-L | Ø90 | 15 | ~0.6' | 3 |
| SR100A | Ø100 | 25 | ~0.56' | 4 |
| SR100A-D (中空) |
Ø100 Ø50通孔 |
20 | ~0.53' | 4 |
| SR100A-L | Ø100 | 20 | ~0.53' | 4 |
| SR110A | Ø110 | 25 | ~0.57' | 4 |
| SR125A | Ø125 | 25 | ~0.46' | 4 |
| SR125A-L | Ø125 | 20 | ~0.46' | 3 |
| SR160A-D (中空) |
Ø158 Ø50通孔 |
30 | ~0.36' | 8 |
