Specifications:
Beam Deviation: <3 arcmin
Clear Aperture: >85%
Face Dimensions Tolerance: +0/-0.2mm
Thickness Tolerance: ±0.25mm
Protective Chamfers: <0.35mm at 45°
Surface Quality: 40-20 S-D
Surface Flatness: <λ/4 @632.8nm
LIDT: >15J/cm2 @1064nm, 10ns
| Model | Wavelength | Size | Transmission (P-Pol./S-Pol.) |
| 7439 | 345-360nm | 6.35 | >96% / <0.1% |
| 7440 | 12.7 | ||
| 7441 | 25.4 | ||
| 7445 | 510-535nm | 6.35 | >96% / <0.1% |
| 7446 | 12.7 | ||
| 7447 | 25.4 | ||
| 7448 | 650-900nm | 6.35 | >92% / <0.15% |
| 7449 | 12.7 | ||
| 7450 | 25.4 | ||
| 7451 | 1025-1080nm | 6.35 | >96% / <0.1% |
| 7452 | 12.7 | ||
| 7453 | 25.4 | ||
| 7454 | 1520-1570nm | 6.35 | >96% / <0.1% |
| 7455 | 12.7 | ||
| 7456 | 25.4 |
